Solid Rocket Motor Igniter
Nammo Space has developed the Igniter for the common Vega-C and Ariane 6 solid rocket motor. The hardware is manufactured from Carbon fiber composite and Aluminium, and is available in quantities of 3 per month. The ignition command is done using an initiator (IFOC). The Igniter consist of a pyrotechnical igniter based on Boron/Potassium Nitrate pellets, and a main igniter with solid propellant.
The carbon fiber reinforced Main Case is able to withstand the thermal loads inside the motor, and keep its shape after the motor functioning phase. The igniter nozzle holes are an integrated part of the carbon fiber composite structure.
Performance Characteristics
Igniter Type
Two step, solid propellant based
Response Time
Please contact Nammo for details
Pressure
< 15 MPa
Envelope
Diameter 1,000 mm, and length 1,000 mm
Mass
< 200 kg
Delivery Condition
Complete, ready for integration
Materials
Carbon composite, Aluminium, propellant, insulation
Signal Interface
IFOC
Structural Interface
Adapter Ring with O-rings
Technology Readiness Level
October, 2021
Status
Please contact Nammo to discuss your specific needs and requirements for the igniter.
