LEROS 2c Apogee Engine
NASA.
The Nammo Space designed and manufactured 321 second Isp, MON/MMH apogee engine delivers a thrust of 430 N.
The engine has been developed using the advances made Nammo engineers in engine injector/chamber assembly design gained from the ESA High Thrust LEROS 4 Engine program, while maintaining the heritage of our long running production programs. This engine, which utilizes relatively inexpensive Niobium alloys with a Titanium expansion cone. The price of this engine approximately 30% lower than current market offerings for this class of high performance apogee engines.
The Nammo Ireland AEV flow control valves, is being offered to the telecommunications and science mission primes. All Nammo apogee engines are hot-fire tested in the UK National Space Propulsion Test Facility at Nammo Westcott. Delivery timescales are typically 12-18 months.
Typical Application
Apogee engine or Main delta V engine
Typical Operational Mode
Please contact Nammo for details of pulse mode capabilities.
Propellant
MON/MMH
Thrust Range
92.2 lbf to 101.2 lbf
Thrust, nominal inlet pressure
96.7 lbf at nominal inlet pressure
Mixture Ratio Range
Oxidiser to Fuel
Mixture Ratio
Oxidiser to Fuel, at nominal inlet pressure
Specific Impulse
321 seconds
Total Impulse
TBD
Propellant Throughput
TBD
Inlet Pressure
223 psia nominal
Inlet Pressure Range
196 psia to 246.6 psia
Restarts
TDB
Maximum Duration Single Firing
6,600 seconds
Cumulative Duration
TBD
Mass
9.3 lb
Nominal Operating Temperature
2,462°F
Propellant Temperature
+39°F to +104°F
Storage Temperature
-63.4°F to +149°F
Storage Life
4 years
Operational Life
19 years
Reliability
0.995
Valve Type
2 off Solenoid, Single Seat, Redundant Coil
Qualified Valve Cycles
10,500 on/off cycles
Valve Voltage
19 Vdc to 27 Vdc
Technology Readiness Level
TRL6
Status
The LEROS 2c is currently under development. Please contact Nammo for further details.
