Mortar Rounds
Photo: Sgt. Jordan Trent
The 120 mm Mortar High Explosive Extended Range (HE-ER) round is a fin-stabilized, naturally fragmenting round intended to be fired from muzzle loading smooth bore mortars or modern breech loaded mortar systems. The round is provided with proximity or point-detonating fuze and is delivered as a ready to fire in 2-round containers, equipped with fuze, charge system and stub case (if required)
The 120 mm Mortar High Explosive (HE) round is a fin-stabilized, naturally fragmenting round intended to be fired from muzzle loading smooth bore mortars or modern breech loaded mortar systems. The round is provided with proximity or point-detonating fuze and is delivered as a ready to fire in 2-round containers, equipped with fuze and charge system.
The 120 mm Mortar Illuminating (MILL) round is used for illumination of target areas during night missions or low visibility conditions. The round functions by way of a time fuze, in a height from 500 m to 700 m wherein the front and rear body are split, ejecting the parachute and illumination kit. Round is delivered as a ready to fire in 2-round containers, equipped with fuze and charge system.
The 120 mm Mortar Infrared Smoke (IR-SMK) round provides visual and infrared screening for several minutes over a wide area. The round functions by way of a time fuze, in a height from 400 m to 500 m wherein the front and rear body are split, ejecting burning smoke pots containing red phosphorus. Round is delivered as a ready to fire in 2-round containers, equipped with fuze and charge system.
The 81 mm Mortar High Explosive (HE) round is a fin-stabilized, naturally fragmenting round intended to be fired from muzzle loading smooth bore mortars. The round is provided with point-detonating fuze and it is delivered as a ready to fire in resealable multi-round containers, equipped with fuze and charge system.
The 81 mm Mortar Illuminating Round is used for illumination of target areas during night missions or low-visibility conditions. The round functions by way of a time fuze, at a height of 400 m wherein the front and rear body are split, ejecting the parachute and illumination kit. The round is delivered as a ready-to-fire in 2-round containers, equipped with fuze and charge system.
The 81 mm Mortar Infrared Smoke (IR-SMK) round provides visual and infrared screening for several minutes over a wide area. The round functions by way of a time fuze, at a height of 400 m wherein the front and rear body are split, ejecting burning smoke pots containing red phosphorus. The round is delivered as a ready-to-fire in 2-round containers, equipped with a fuze and charge system.
Provides safe, realistic and low cost training for mortar crews, forward observers and fire direction control personnel. This ammunition is full caliber (not a sabot) and is ready to fire in all weather conditions. Pyrotechnic impact signature does not cause fragments and provides excellent fire adjustment training.
