Nammo Space has developed a simple, small screw-in device for propellant and fluid loading and unloading in small spacecraft applications.  The threaded interface can be screwed directly into the tank in your propulsion system.  This interface is sealed using an o-ring.

A simple Ground Half Coupling [GHC] supplied with the valve.  The adaptor is screw onto body of the Flight Half Coupling and displaces the seal thus permitting a flow path through the valve to the tank.  The action of unscrewing the GHC adaptor closes the valve, and the compression spring returns the valve to a sealed mode.  The hardware is made from Aluminium and weighs less than 23g.

Status

The HTP Fill and Drain Valve has been designed and produced for Newspace applications.

NAMMO CHELTENHAM

GENERAL CAPABILITIES

• Dedicated, skilled space engineering team
• Experienced Assembly Integration and Test team
• Program Management

QUALITY AND INSPECTION

• Certified to AS9100
• Inspection department including CMM and optical measuring equipment
• Laser part marking
• Complete traceability of inspection records
• Material traceability from original mill source to final components

CLEANROOM and ENVIRONMENTAL TESTING

• ISO Class 8 environment, with Class 5 laminar flow booths
• Large 1m diameter x 2m long Vacuum chamber
• Thermal vacuum chambers
• Thrust test facility
• Vacuum/leak testing and pressure testing.
• Air borne and liquid Particle measurement.
• Pressure Test facility to 1500 bar
• Computer controlled TIG and Orbital TIG weld facility
