20 mm x 139 Multipurpose Tracer Self-Destruct

20 mm x 139 Multipurpose Tracer Self-Destruct

The 20 mm x 139 Multipurpose ammunition with tracer and self-destruct device is designed to defeat a broad spectrum of targets, ranging from all kinds of soft skinned air and ground targets up to light armored and semi-hard targets. The tracer gives the shooter target correction information and the self-destruct device minimizes the risk for collateral damage. The hardened steel body with explosive filling gives significant penetration, blast, incendiary and fragmentation effects. The pyrotechnical initiation chain gives a natural delay ensuring all effects are delivered inside the target.

Product specifications

Projectile weight

122 g

Muzzle velocity

1 045 m/s

Tracer

≥ 3.7 s

Self-destruction

Yes

Dispersion

≤ 0.2 m x 0.6745 at 200 m

Service temperature

-40°C to +50°C

Status

Designated by BAAINBw in Germany with the number DM91 and the Norwegian Army with NM75 F2. Qualified for use in the Mk20 Rh202, the Giat F2 gun and the Denel GI-2.
